ON Semiconductor FDG6332C-F085

Part No.:: FDG6332C-F085

Manufacturer:: ON Semiconductor

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: FDG6332C-F085.pdf

Description:: MOSFET N/P-CH 20V SC70-6

In Stock:: 3310

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FDG6332C-F085 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101, PowerTrench®
ProductStatus:
Obsolete
FETType:
N and P-Channel
FETFeature:
Logic Level Gate
DraintoSourceVoltage(Vdss):
20V
Current-ContinuousDrain(Id)@25°C:
700mA, 600mA
RdsOn(Max)@IdVgs:
300mOhm @ 700mA, 4.5V
Vgs(th)(Max)@Id:
1.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
1.5nC @ 4.5V
InputCapacitance(Ciss)(Max)@Vds:
113pF @ 10V
Power-Max:
300mW
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
