Diodes Incorporated BSS84V-7-79

Part No.:: BSS84V-7-79

Manufacturer:: Diodes Incorporated

Package:: SOT-563, SOT-666

Datasheet:

Description:: DIODE

In Stock:: 2618

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BSS84V-7-79 Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Obsolete
FETType:
2 P-Channel (Dual)
FETFeature:
Standard
DraintoSourceVoltage(Vdss):
50V
Current-ContinuousDrain(Id)@25°C:
130mA (Ta)
RdsOn(Max)@IdVgs:
10Ohm @ 100mA, 5V
Vgs(th)(Max)@Id:
2V @ 1mA
GateCharge(Qg)(Max)@Vgs:
-
InputCapacitance(Ciss)(Max)@Vds:
45pF @ 25V
Power-Max:
150mW (Ta)
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
