Micro Commercial Co BSS84DW-TP

Part No.:: BSS84DW-TP

Manufacturer:: Micro Commercial Co

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: BSS84DW-TP.pdf

Description:: DUAL P CHANNEL MOSFET, SOT-363

In Stock:: 3770

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BSS84DW-TP Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
FETType:
2 P-Channel (Dual)
FETFeature:
Standard
DraintoSourceVoltage(Vdss):
50V
Current-ContinuousDrain(Id)@25°C:
160mA
RdsOn(Max)@IdVgs:
8Ohm @ 100mA, 10V
Vgs(th)(Max)@Id:
2V @ 250µA
GateCharge(Qg)(Max)@Vgs:
-
InputCapacitance(Ciss)(Max)@Vds:
30pF @ 25V
Power-Max:
450mW
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
