Alpha & Omega Semiconductor Inc. AO4606L_DELTA

Part No.:: AO4606L_DELTA

Manufacturer:: Alpha & Omega Semiconductor Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:

Description:: MOSFET N-CH 8SOIC

In Stock:: 2399

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AO4606L_DELTA Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
FETType:
N and P-Channel Complementary
FETFeature:
Standard
DraintoSourceVoltage(Vdss):
30V
Current-ContinuousDrain(Id)@25°C:
6A
RdsOn(Max)@IdVgs:
30mOhm @ 6A, 10V
Vgs(th)(Max)@Id:
2.4V @ 250µA
GateCharge(Qg)(Max)@Vgs:
6nC @ 10V
InputCapacitance(Ciss)(Max)@Vds:
310pF @ 15V
Power-Max:
2W
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount

AO4606L_DELTA this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AO4606L_DELTA price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AO4606L_DELTA to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AO4606L_DELTA information

Views：

AO4606L_DELTA Typical application Circuitry

AO4606L_DELTA

The AO4606L_DELTA is a dual MOSFET chip, integrating two MOSFETs into one package. This type of chip is typically used in applications requiring efficient power management and space-saving solutions, combining both n-channel and p-channel MOSFETs in a single package.

1. Functionality: The AO4606L_DELTA serves as a dual-function switch in electronic circuits, enabling the efficient control of high current in both directions with minimal power loss.

2. Application Scenarios: One typical application of the AO4606L_DELTA is in synchronous buck converters, which are commonly used in power supply circuits to step down voltage efficiently.

3. Parameter Characteristics:

- Drain-Source Voltage: This is the maximum voltage the MOSFET can handle across its drain and source.

- On-Resistance: Indicates the MOSFET's resistance in the conducting state. - Maximum Drain Current: The maximum current that a MOSFET can handle without risk.

4. Circuit Connection for a Synchronous Buck Converter:

- High-Side MOSFET (p-channel): Connect the drain of the p-channel MOSFET to the input voltage source. The source pin should be connected to the inductor, which is part of the output stage of the buck converter.

- Low-Side MOSFET (n-channel): Attach the source pin of the n-channel MOSFET to the ground. Its drain should be connected to the same node as the p-channel MOSFET's source (the inductor).

- Gate Drive Circuitry: The gate pins of both MOSFETs are controlled by a gate driver circuit, which is crucial for the MOSFETs' switching operation.

5. Design Considerations:

- Thermal Management: Due to the dual nature of the AO4606L_DELTA, it is vital to consider heat dissipation, as both MOSFETs can generate significant heat.

- Voltage and Current Ratings: The circuit must be designed within the voltage and current limits of the AO4606L_DELTA.

- Dead Time Control: Proper dead time control between the switching of the n-channel and p-channel MOSFETs is critical to prevent shoot-through.

Incorporating the AO4606L_DELTA in a synchronous buck converter requires careful attention to its thermal behavior, ensuring the electrical specifications are within limits, and precise control of the switching times for optimal efficiency and performance.
