Name: 2N7002KDW-TP
Brand: Micro Commercial Co
SKU: 2N7002KDW-TP
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Micro Commercial Co 2N7002KDW-TP

Part No.:: 2N7002KDW-TP

Manufacturer:: Micro Commercial Co

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: 2N7002KDW-TP.pdf

Description:: N-CHANNEL,MOSFETS,SOT-363 PACKAG

In Stock:: 2176

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

2N7002KDW-TP Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
FETType:
2 N-Channel (Dual)
FETFeature:
Standard
DraintoSourceVoltage(Vdss):
60V
Current-ContinuousDrain(Id)@25°C:
340mA
RdsOn(Max)@IdVgs:
5Ohm @ 500mA, 10V
Vgs(th)(Max)@Id:
2.5V @ 1mA
GateCharge(Qg)(Max)@Vgs:
-
InputCapacitance(Ciss)(Max)@Vds:
40pF @ 10V
Power-Max:
150mW
OperatingTemperature:
-55°C ~ 150°C
MountingType:
Surface Mount
