Nexperia USA Inc. 2N7002BKV,115

Part No.:: 2N7002BKV,115

Manufacturer:: Nexperia USA Inc.

Package:: SOT-563, SOT-666

Datasheet:: 2N7002BKV,115.pdf

Description:: MOSFET 2N-CH 60V 340MA SOT666

In Stock:: 3257

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

2N7002BKV,115 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101, TrenchMOS™
ProductStatus:
Not For New Designs
FETType:
2 N-Channel (Dual)
FETFeature:
Logic Level Gate
DraintoSourceVoltage(Vdss):
60V
Current-ContinuousDrain(Id)@25°C:
340mA
RdsOn(Max)@IdVgs:
1.6Ohm @ 500mA, 10V
Vgs(th)(Max)@Id:
2.1V @ 250µA
GateCharge(Qg)(Max)@Vgs:
0.6nC @ 4.5V
InputCapacitance(Ciss)(Max)@Vds:
50pF @ 10V
Power-Max:
350mW
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
