Ampleon USA Inc. BLF574XRS,112

Part No.:: BLF574XRS,112

Manufacturer:: Ampleon USA Inc.

Package:: SOT-1214B

Datasheet:: BLF574XRS,112.pdf

Description:: RF FET LDMOS 110V 23DB SOT1214B

In Stock:: 2190

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BLF574XRS,112 Specifications

Packaging:
Tray
Series:
-
ProductStatus:
Active
TransistorType:
LDMOS (Dual), Common Source
Frequency:
225MHz
Gain:
23.5dB
Voltage-Test:
50 V
CurrentRating(Amps):
-
NoiseFigure:
-
Current-Test:
100 mA
Power-Output:
600W
Voltage-Rated:
110 V
