TDK Corporation ACT45B-220-2P-TL003

Part No.:: ACT45B-220-2P-TL003

Manufacturer:: TDK Corporation

Package:

Datasheet:

Description:: CMC 22UH 200MA 2LN SMD AEC-Q200

In Stock:: 3337

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ACT45B-220-2P-TL003 Specifications

Package/Case:
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
ACT
ProductStatus:
Active
FilterType:
Signal Line
NumberofLines:
2
Impedance@Frequency:
1.2 kOhms @ 10 MHz
Inductance@Frequency:
22 µH @ 100 kHz
CurrentRating(Max):
200mA
DCResistance(DCR)(Max):
1Ohm
VoltageRating-DC:
50V
VoltageRating-AC:
-
OperatingTemperature:
-40°C ~ 150°C
Ratings:
AEC-Q200
ApprovalAgency:
-
Features:
-
MountingType:
Surface Mount
Size/Dimension:
0.177 L x 0.126 W (4.50mm x 3.20mm)
Height(Max):
0.118 (3.00mm)
