Texas Instruments TPD4E05U06DQAR

Part No.:: TPD4E05U06DQAR

Manufacturer:: Texas Instruments

Package:: 10-UFDFN

Datasheet:: TPD4E05U06DQAR.pdf

Description:: TVS DIODE 5.5VWM 14VC 10USON

In Stock:: 2758

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TPD4E05U06DQAR Specifications

Package/Case:
10-UFDFN
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
Steering (Rail to Rail)
UnidirectionalChannels:
4
BidirectionalChannels:
-
Voltage-ReverseStandoff(Typ):
5.5V (Max)
Voltage-Breakdown(Min):
6V
Voltage-Clamping(Max)@Ipp:
14V
Current-PeakPulse(10/1000µs):
2.5A (8/20µs)
Power-PeakPulse:
40W
PowerLineProtection:
Yes
Applications:
HDMI
Capacitance@Frequency:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
