Name: TLP5701(D4,E
Brand: Toshiba Semiconductor and Storage
SKU: TLP5701(D4,E
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Toshiba Semiconductor and Storage TLP5701(D4,E

Part No.:: TLP5701(D4,E

Manufacturer:: Toshiba Semiconductor and Storage

Package:: 6-SOIC (0.295, 7.50mm Width)

Datasheet:: TLP5701(D4,E.pdf

Description:: X36 PB-F DRIVER COUPLER 0.6A SO6

In Stock:: 3128

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLP5701(D4,E Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Active
NumberofChannels:
1
Inputs-Side1/Side2:
1/0
Voltage-Isolation:
5000Vrms
CommonModeTransientImmunity(Min):
20kV/µs
InputType:
DC
OutputType:
Push-Pull, Totem Pole
Current-Output/Channel:
600 mA
DataRate:
-
PropagationDelaytpLH/tpHL(Max):
500ns, 500ns
Rise/FallTime(Typ):
50ns, 50ns
Voltage-Forward(Vf)(Typ):
1.57V
Current-DCForward(If)(Max):
25mA
Voltage-Supply:
10V ~ 30V
OperatingTemperature:
-40°C ~ 110°C
MountingType:
Surface Mount
