Taiwan Semiconductor Corporation SMBJ15CAHM4G

Part No.:: SMBJ15CAHM4G

Manufacturer:: Taiwan Semiconductor Corporation

Package:: DO-214AA, SMB

Datasheet:: SMBJ15CAHM4G.pdf

Description:: TVS DIODE 15VWM 24.4VC DO214AA

In Stock:: 3795

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SMBJ15CAHM4G Specifications

Package/Case:
DO-214AA, SMB
Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q101, SMBJ
ProductStatus:
Discontinued at Mosen
Type:
Zener
UnidirectionalChannels:
-
BidirectionalChannels:
1
Voltage-ReverseStandoff(Typ):
15V
Voltage-Breakdown(Min):
16.7V
Voltage-Clamping(Max)@Ipp:
24.4V
Current-PeakPulse(10/1000µs):
25.1A
Power-PeakPulse:
600W
PowerLineProtection:
No
Applications:
Automotive
Capacitance@Frequency:
-
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
