Name: SKY67159-396LF
Brand: Skyworks Solutions Inc.
SKU: SKY67159-396LF
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Skyworks Solutions Inc. SKY67159-396LF

Part No.:: SKY67159-396LF

Manufacturer:: Skyworks Solutions Inc.

Package:: 8-WFDFN Exposed Pad

Datasheet:: SKY67159-396LF.pdf

Description:: IC AMP 3G/4G 200MHZ-3.8GHZ 8DFN

In Stock:: 2782

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SKY67159-396LF Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Frequency:
200MHz ~ 3.8GHz
P1dB:
18dBm
Gain:
16.8dB
NoiseFigure:
1.3dB
RFType:
3G/4G
Voltage-Supply:
3.3V
Current-Supply:
45mA
TestFrequency:
-
MountingType:
Surface Mount
