Epson RX8010SJ:B3 PURE SN

Part No.:: RX8010SJ:B3 PURE SN

Manufacturer:: Epson

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: RX8010SJ:B3 PURE SN.pdf

Description:: IC RTC CLK/CALENDAR I2C 8-SOP

In Stock:: 3355

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

RX8010SJ:B3 PURE SN Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR)
Series:
RX8010SJ
ProductStatus:
Active
Type:
Clock/Calendar
Features:
Alarm, Leap Year, RAM
MemorySize:
16B
TimeFormat:
HH:MM:SS (24 hr)
DateFormat:
YY-MM-DD-dd
Interface:
I²C, 2-Wire Serial
Voltage-Supply:
1.6V ~ 5.5V
Voltage-SupplyBattery:
-
Current-Timekeeping(Max):
0.32µA ~ 0.35µA @ 3V ~ 5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
