NXP USA Inc. PCF85063ATL/1,118

Part No.:: PCF85063ATL/1,118

Manufacturer:: NXP USA Inc.

Package:: 10-XFDFN Exposed Pad

Datasheet:: PCF85063ATL/1,118.pdf

Description:: IC RTC CLK/CALENDAR I2C 10-SON

In Stock:: 50910

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PCF85063ATL/1,118 Specifications

Package/Case:
10-XFDFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
Clock/Calendar
Features:
Alarm, Leap Year, Square Wave Output
MemorySize:
-
TimeFormat:
HH:MM:SS (12/24 hr)
DateFormat:
YY-MM-DD-dd
Interface:
I²C, 2-Wire Serial
Voltage-Supply:
0.9V ~ 5.5V
Voltage-SupplyBattery:
-
Current-Timekeeping(Max):
0.6µA @ 3.3V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

PCF85063ATL/1,118 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including PCF85063ATL/1,118 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for PCF85063ATL/1,118 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

PCF85063ATL/1,118 information

Views：

PCF85063ATL/1,118 Typical application Circuitry

PCF85063ATL 1,118

The PCF85063ATL/1,118 is a real-time clock (RTC) and calendar integrated circuit created by NXP Semiconductors. It is designed for precise timekeeping and calendar functionalities, making it suitable for a wide range of applications where accurate time and date tracking are essential.

Application Scenarios

The PCF85063ATL/1,118 is commonly used in embedded systems, consumer electronics like digital clocks and smartwatches, data logging systems, and in industrial controls where time stamping or scheduling is required.

Parameter Features

Key features of the PCF85063ATL/1,118 include:

- Accurate real-time clock and calendar capabilities.

- Low power consumption.

- Integrated timer and alarm features.

- An I/C-bus interface that makes microcontroller integration simple.

Application Scenario - Smartwatch: Circuit Connection Method

1. I²C Communication Setup: Establish a connection by linking the SDA (Serial Data) and SCL (Serial Clock) pins of the PCF85063ATL/1,118 to the respective I²C bus lines of the microcontroller located inside the smartwatch.

2. Power Connections: Ensure the VSS pin is grounded while connecting the VDD pin to a 3.3V power source.To ensure precise RTC performance, make sure the power supply is steady.

3. External Oscillator Connection: For precise timekeeping, connect a 32.768 kHz crystal oscillator to the XTAL1 and XTAL2 pins.

4. Backup Power Source: Implement a backup power source like a coin cell battery, connecting it to the VBAT pin, ensuring continuous timekeeping even when the main power supply is off.

Circuit Design Considerations of PCF85063ATL/1,118

- Stable Power Supply: A clean and stable power supply is critical for maintaining the accuracy of the RTC.

- Crystal Oscillator Placement: Ensure the crystal oscillator is placed close to the XTAL pins and isolated from sources of electrical noise.

- To ensure the integrity of the I²C bus, it is essential to include suitable pull-up resistors on the I²C lines and keep the bus length short, thereby ensuring dependable communication.

- Backup Power Management: A reliable backup power system is essential for continuous timekeeping during power interruptions.

In a smartwatch application, the PCF85063ATL/1,118 plays a vital role in providing accurate time and date information. Its integration into the smartwatch circuit allows for various time-related functions, enhancing the overall utility of the device.
