Epson RTC-4543SA:B ROHS

Part No.:: RTC-4543SA:B ROHS

Manufacturer:: Epson

Package:: 14-SOIC (0.197, 5.00mm Width)

Datasheet:: RTC-4543SA:B ROHS.pdf

Description:: IC RTC CALENDAR 3-WIRE SER 14SOP

In Stock:: 2797

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

RTC-4543SA:B ROHS Specifications

Package/Case:
14-SOIC (0.197, 5.00mm Width)
Packaging:
Tube
Series:
RTC-4543SA
ProductStatus:
Obsolete
Type:
Clock/Calendar
Features:
Leap Year
MemorySize:
-
TimeFormat:
HH:MM:SS (24 hr)
DateFormat:
YY-MM-DD-dd
Interface:
3-Wire Serial
Voltage-Supply:
2.5V ~ 5.5V
Voltage-SupplyBattery:
-
Current-Timekeeping(Max):
1µA ~ 3µA @ 2V ~ 5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
