NXP USA Inc. MPX5700AP

Part No.:: MPX5700AP

Manufacturer:: NXP USA Inc.

Package:: 6-SIP Module

Datasheet:: MPX5700AP.pdf

Description:: IC PRESSURE SENSOR ABS 6-SIP

In Stock:: 2442

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MPX5700AP Specifications

Package/Case:
6-SIP Module
Packaging:
Tray
Series:
MPX5700
ProductStatus:
Active
Applications:
Board Mount
PressureType:
Absolute
OperatingPressure:
2.18PSI ~ 101.53PSI (15kPa ~ 700kPa)
OutputType:
Analog Voltage
Output:
0.2 V ~ 4.7 V
Accuracy:
±2.5%
Voltage-Supply:
4.75V ~ 5.25V
PortSize:
Male - 0.19 (4.93mm) Tube
PortStyle:
Barbed
Features:
Temperature Compensated
TerminationStyle:
PC Pin
MaximumPressure:
406.11PSI (2800kPa)
OperatingTemperature:
-40°C ~ 125°C

MPX5700AP this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including MPX5700AP price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for MPX5700AP to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

MPX5700AP information

Views：

MPX5700AP Typical application Circuitry

The MPX5700AP is a pressure sensor produced by NXP Semiconductor, designed to sense and respond to changes in pressure.

A key strength of the MPX5700AP is its broad range of potential applications. It is most frequently utilized in areas such as medical systems, HVAC systems, automotive systems, and industrial controls where accurate pressure sensing is needed.

Key features of the MPX5700AP include an operating temperature range of -40°C to 125°C, a pressure range of 15-700 kPa, and an accuracy of ±2.5% of the reading. It also offers an analog output voltage that is proportional to the pressure.

Let's consider a specific application scenario for the MPX5700AP: creating a weather monitoring system that involves measuring atmospheric pressure.

1. Power Supply: You'll start by supplying 5V power to the Pin 2 (Vcc) and ground to Pin 3 (GND).

2. Analog Output: The output from the MPX5700AP can be found on Pin 4 (Vout), which provides an analog voltage signal proportional to the atmospheric pressure. This output needs to be connected to the analog-to-digital converter (ADC) in the microcontroller for digitization and further processing.

3. Pressure Input: The pressure port of the MPX5700AP should be exposed to the atmosphere in this setup to measure the pressure changes.

During the design process, some essential considerations when using the MPX5700AP are:

- Shielding: Given its sensitivity, the MPX5700AP must be appropriately shielded from intense pressures, corrosive chemicals, and physical impacts to ensure its longevity and reliable operation.

- Power Supply: The power supplied to the MPX5700AP should be stable and devoid of high-frequency noise to avoid negatively influencing the accuracy of the sensor's readings. Decoupling capacitors between Vcc and GND can help achieve this.

- Signal Conditioning: Depending on the application's specific requirements, a signal conditioning circuit may be necessary to amplify or filter the output of the MPX5700AP.

- Temperature Fluctuations: If the MPX5700AP will be operating in an environment with significant temperature variations, implementing temperature compensation strategies can help maintain accuracy.

To sum up, the MPX5700AP is a versatile and efficient pressure sensor suitable for a myriad of applications. Proper incorporation of this sensor into your circuit design is key to fully unlocking its capabilities.
