Name: HMC8412LP2FE
Brand: Analog Devices Inc.
SKU: HMC8412LP2FE
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. HMC8412LP2FE

Part No.:: HMC8412LP2FE

Manufacturer:: Analog Devices Inc.

Package:: 6-VDFN Exposed Pad, CSP

Datasheet:: HMC8412LP2FE.pdf

Description:: LNA 0.4 11 GHZ

In Stock:: 182

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HMC8412LP2FE Specifications

Packaging:
Strip
Series:
-
ProductStatus:
Active
Frequency:
400MHz ~ 11GHz
P1dB:
18dBm
Gain:
14dB
NoiseFigure:
1.8dB
RFType:
Radar
Voltage-Supply:
2V ~ 6V
Current-Supply:
60mA
TestFrequency:
400MHz ~ 9GHz
MountingType:
Surface Mount
