Analog Devices Inc. HMC7950LS6TR

Part No.:: HMC7950LS6TR

Manufacturer:: Analog Devices Inc.

Package:: 16-CLCC Exposed Pad

Datasheet:: HMC7950LS6TR.pdf

Description:: IC RF AMP 2GHZ-28GHZ 16LCC-HS

In Stock:: 100

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HMC7950LS6TR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Frequency:
2GHz ~ 28GHz
P1dB:
16dBm
Gain:
15dB
NoiseFigure:
3dB
RFType:
-
Voltage-Supply:
5V
Current-Supply:
64mA
TestFrequency:
-
MountingType:
Surface Mount
