Analog Devices Inc. HMC406MS8GE

Part No.:: HMC406MS8GE

Manufacturer:: Analog Devices Inc.

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad

Datasheet:: HMC406MS8GE.pdf

Description:: IC RF AMP WIMAX 5GHZ-6GHZ 8MSOP

In Stock:: 2298

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HMC406MS8GE Specifications

Packaging:
Strip
Series:
-
ProductStatus:
Active
Frequency:
5GHz ~ 6GHz
P1dB:
27dBm
Gain:
17dB
NoiseFigure:
6dB
RFType:
WiMax, WLAN
Voltage-Supply:
5V
Current-Supply:
300mA
TestFrequency:
5.8GHz
MountingType:
Surface Mount
