Analog Devices Inc. HMC383

Part No.:: HMC383

Manufacturer:: Analog Devices Inc.

Package:: Die

Datasheet:: HMC383.pdf

Description:: IC RF AMP VSAT 12GHZ-30GHZ DIE

In Stock:: 3572

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HMC383 Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Active
Frequency:
12GHz ~ 30GHz
P1dB:
16.5dB
Gain:
17dB
NoiseFigure:
9dB
RFType:
VSAT
Voltage-Supply:
5V
Current-Supply:
101mA
TestFrequency:
12GHz ~ 18GHz
MountingType:
Surface Mount
