onsemi HCPL2630

Part No.:: HCPL2630

Manufacturer:: onsemi

Package:: 8-DIP (0.300, 7.62mm)

Datasheet:: HCPL2630.pdf

Description:: OPTOISO 2.5KV 2CH OPEN COLL 8DIP

In Stock:: 3358

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HCPL2630 Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Last Time Buy
NumberofChannels:
2
Inputs-Side1/Side2:
2/0
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
10kV/µs (Typ)
InputType:
DC
OutputType:
Open Collector
Current-Output/Channel:
50 mA
DataRate:
10Mbps
PropagationDelaytpLH/tpHL(Max):
75ns, 75ns
Rise/FallTime(Typ):
50ns, 12ns
Voltage-Forward(Vf)(Typ):
1.4V
Current-DCForward(If)(Max):
30mA
Voltage-Supply:
4.5V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Through Hole
