Name: HCPL-5631
Brand: Broadcom Limited
SKU: HCPL-5631
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Broadcom Limited HCPL-5631

Part No.:: HCPL-5631

Manufacturer:: Broadcom Limited

Package:: 8-DIP (0.300, 7.62mm)

Datasheet:: HCPL-5631.pdf

Description:: OPTOISO 1.5KV 2CH OPEN COLL 8DIP

In Stock:: 2228

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HCPL-5631 Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Active
NumberofChannels:
2
Inputs-Side1/Side2:
2/0
Voltage-Isolation:
1500VDC
CommonModeTransientImmunity(Min):
1kV/µs
InputType:
DC
OutputType:
Open Collector, Schottky Clamped
Current-Output/Channel:
25 mA
DataRate:
10MBd
PropagationDelaytpLH/tpHL(Max):
100ns, 100ns
Rise/FallTime(Typ):
35ns, 35ns
Voltage-Forward(Vf)(Typ):
1.5V
Current-DCForward(If)(Max):
20mA
Voltage-Supply:
4.5V ~ 5.5V
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Through Hole
