STMicroelectronics ESDCAN02-2BWY

Part No.:: ESDCAN02-2BWY

Manufacturer:: STMicroelectronics

Package:: SC-70, SOT-323

Datasheet:: ESDCAN02-2BWY.pdf

Description:: TVS DIODE 26.5VWM 44VC SOT323-3

In Stock:: 3951

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ESDCAN02-2BWY Specifications

Package/Case:
SC-70, SOT-323
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
ProductStatus:
Active
Type:
Zener
UnidirectionalChannels:
-
BidirectionalChannels:
2
Voltage-ReverseStandoff(Typ):
26.5V (Max)
Voltage-Breakdown(Min):
28.5V
Voltage-Clamping(Max)@Ipp:
44V
Current-PeakPulse(10/1000µs):
3A (8/20µs)
Power-PeakPulse:
250W
PowerLineProtection:
No
Applications:
Automotive, CAN
Capacitance@Frequency:
3pF @ 1MHz
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Surface Mount

ESDCAN02-2BWY this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ESDCAN02-2BWY price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ESDCAN02-2BWY to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ESDCAN02-2BWY information

Views：

ESDCAN02-2BWY Typical application Circuitry

ESDCAN02-2BWY

The ESDCAN02-2BWY chip is a dedicated electrostatic discharge (ESD) protection device specifically designed for Controller Area Network (CAN) bus systems. It is engineered to safeguard sensitive CAN transceivers against ESD and other transient voltage events, making it an essential component in automotive and industrial applications.

Functionality: The ESDCAN02-2BWY provides bidirectional ESD protection for CAN bus lines, ensuring the integrity of data communication in harsh environments.The IEC 61000-4-2 standard states that it can survive ESD occurrences up to ±30 kV (air discharge) and ±30 kV (contact discharge).

Applications: This chip is widely utilized in automobile electronics, where dependable CAN bus connection is essential, such as in engine control units (ECUs), body control modules (BCMs), and infotainment systems. Medical equipment, industrial automation systems, and other applications needing strong CAN communication can also use it.

Specifications: The ESDCAN02-2BWY features a low clamping voltage, typically around 40 V, to provide effective protection while maintaining signal integrity. It has a low capacitance of about 3 pF, ensuring minimal impact on the signal quality of the CAN bus.

Circuit Design for an Automotive ECU:

- Power Supply Connection: Connect the ESDCAN02-2BWY to the 5V power supply line with a decoupling capacitor close to the chip to filter out noise.

- CAN Bus Lines: Connect the CANH and CANL lines from the CAN transceiver to the corresponding pins on the ESDCAN02-2BWY to provide ESD protection.

- Ground Connection: Connect the ground pin of the ESDCAN02-2BWY to the system ground to ensure a low-impedance path for dissipating ESD energy.

- Filtering Capacitors: Add capacitors between the CANH and CANL lines and ground to filter out high-frequency noise and enhance ESD protection.

Design Considerations: When designing a circuit with the ESDCAN02-2BWY, it is crucial to minimize the parasitic inductance by keeping the traces short and using a multilayer PCB with a dedicated ground plane. The layout should ensure that the ESD path is direct and has low impedance. Additionally, it is essential to consider the thermal characteristics of the chip and provide adequate heat dissipation if necessary.

In conclusion, the ESDCAN02-2BWY is a specialized chip designed to provide robust ESD protection for CAN bus systems in automotive and industrial applications. Its low clamping voltage, low capacitance, and high ESD withstand capability make it an ideal choice for ensuring reliable communication in harsh environments.
