Name: BFR92A,235
Brand: NXP USA Inc.
SKU: BFR92A,235
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

NXP USA Inc. BFR92A,235

Part No.:: BFR92A,235

Manufacturer:: NXP USA Inc.

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: BFR92A,235.pdf

Description:: RF TRANS NPN 15V 5GHZ TO236AB

In Stock:: 3072

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BFR92A,235 Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
TransistorType:
NPN
Voltage-CollectorEmitterBreakdown(Max):
15V
Frequency-Transition:
5GHz
NoiseFigure(dBTyp@f):
2.1dB ~ 3dB @ 1GHz ~ 2GHz
Gain:
-
Power-Max:
300mW
DCCurrentGain(hFE)(Min)@IcVce:
65 @ 15mA, 10V
Current-Collector(Ic)(Max):
25mA
OperatingTemperature:
175°C (TJ)
MountingType:
Surface Mount
