Analog Devices Inc. AD9912ABCPZ

Part No.:: AD9912ABCPZ

Manufacturer:: Analog Devices Inc.

Package:: 64-VFQFN Exposed Pad, CSP

Datasheet:

Description:: IC DDS 1GHZ 14BIT 64LFCSP

In Stock:: 176

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD9912ABCPZ Specifications

Package/Case:
64-VFQFN Exposed Pad, CSP
Packaging:
Tray
Series:
-
ProductStatus:
Active
Resolution(Bits):
14 b
Masterfclk:
1 GHz
TuningWordWidth(Bits):
48 b
Voltage-Supply:
1.8V, 3.3V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
