Analog Devices Inc. AD9852ASVZ

Part No.:: AD9852ASVZ

Manufacturer:: Analog Devices Inc.

Package:: 80-TQFP Exposed Pad

Datasheet:: AD9852ASVZ.pdf

Description:: IC DDS 300MHZ 12BIT 80TQFP

In Stock:: 394

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD9852ASVZ Specifications

Package/Case:
80-TQFP Exposed Pad
Packaging:
Tray
Series:
-
ProductStatus:
Active
Resolution(Bits):
12 b
Masterfclk:
300 MHz
TuningWordWidth(Bits):
48 b
Voltage-Supply:
3.14V ~ 3.47V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
