Fairchild Semiconductor 6N137SV

Part No.:: 6N137SV

Manufacturer:: Fairchild Semiconductor

Package:: 8-SMD, Gull Wing

Datasheet:: 6N137SV.pdf

Description:: LOGIC IC OUTPUT OPTOCOUPLER

In Stock:: 2877

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

6N137SV Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Obsolete
NumberofChannels:
1
Inputs-Side1/Side2:
1/0
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
10kV/µs (Typ)
InputType:
DC
OutputType:
Open Collector
Current-Output/Channel:
50 mA
DataRate:
10Mbps
PropagationDelaytpLH/tpHL(Max):
75ns, 75ns
Rise/FallTime(Typ):
50ns, 12ns
Voltage-Forward(Vf)(Typ):
1.4V
Current-DCForward(If)(Max):
50mA
Voltage-Supply:
4.5V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
