Texas Instruments TCA6408ARSVR

Part No.:: TCA6408ARSVR

Manufacturer:: Texas Instruments

Package:: 16-UFQFN

Datasheet:: TCA6408ARSVR.pdf

Description:: IC I/O EXPANDER I2C 8B 16QFN

In Stock:: 2498

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TCA6408ARSVR Specifications

Package/Case:
16-UFQFN
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
NumberofI/O:
8
Interface:
I²C, SMBus
InterruptOutput:
Yes
Features:
POR
OutputType:
Push-Pull
Current-OutputSource/Sink:
10mA, 25mA
ClockFrequency:
400 kHz
Voltage-Supply:
1.65V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

TCA6408ARSVR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including TCA6408ARSVR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for TCA6408ARSVR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

TCA6408ARSVR information

Views：

TCA6408ARSVR Typical application Circuitry

TCA6408ARSVR

TCA6408ARSVR is a type of integrated circuit primarily used as an 8-bit I/O expander for the two-line bidirectional I²C bus (serial clock (SCL), serial data (SDA)). It's designed to provide general-purpose remote I/O expansion for most microcontroller families, which is particularly useful in applications where additional I/Os are needed. The chip is commonly utilized in applications like mobile devices, gaming consoles, and industrial control systems. Let's delve into its features and a specific application scenario.

Key Features of TCA6408ARSVR

1. 8-Bit I/O Expander: Equipped with 8 I/O ports that can be independently configured as input or output.

2. I2C Interface Compatibility: Allows for simple integration with a variety of microcontrollers by supporting I2C communication.

3. Low Standby Current: Ideal for power-sensitive applications due to its low standby current.

4. Polarity Inversion: Offers polarity inversion registers, allowing the inversion of the polarity of the I/O pins.

Use Case: Industrial Management System

The TCA6408ARSVR can be used to control various input and output signals in an industrial control system. Here's a detailed circuit connection method:

1. I2C Communication Setup: Connect the SDA and SCL pins of TCA6408ARSVR to the corresponding I2C bus lines of the microcontroller. This is essential for the microcontroller and I/O expander's I2C communication.

2. Connections to the Power Supply: Verify that the TCA6408ARSVR is linked to a steady voltage source. The operating voltage range is typically from 1.65V to 5.5V, making it essential to match the power supply to these specifications for reliable operation.

3. I/O Pin Configuration: Connect sensors, actuators, or other peripherals to the P0 to P7 pins of TCA6408ARSVR. Every pin can have its own configuration as an input or an output, based on what the application needs.

4. Interrupt Line Integration: The INT pin on the microcontroller needs to be linked to an interrupt input. This allows the microcontroller to be promptly informed about changes in the input states, improving system responsiveness.

5. Address Pin Settings: The A0, A1, and A2 address pins need to be configured for the desired I2C address of TCA6408ARSVR. This is particularly important when multiple devices are connected to the same I2C bus.

6. Design for Electromagnetic Interference (EMI): Because of the industrial setting, it's critical to limit EMI in the PCB design, since it may affect the TCA6408ARSVR's performance.

In conclusion, integrating TCA6408ARSVR into an industrial control system involves meticulous attention to I2C communication setup, power supply connections, I/O pin configuration, interrupt line integration, address pin settings, and EMI considerations. These factors are key to ensuring efficient and reliable I/O expansion in industrial applications.
