Texas Instruments PCA9538PWR

Part No.:: PCA9538PWR

Manufacturer:: Texas Instruments

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: PCA9538PWR.pdf

Description:: IC I/O EXPANDER I2C 8B 16TSSOP

In Stock:: 3562

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PCA9538PWR Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
NumberofI/O:
8
Interface:
I²C, SMBus
InterruptOutput:
Yes
Features:
POR
OutputType:
Push-Pull
Current-OutputSource/Sink:
10mA, 25mA
ClockFrequency:
400 kHz
Voltage-Supply:
2.3V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

PCA9538PWR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including PCA9538PWR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for PCA9538PWR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

PCA9538PWR information

Views：

PCA9538PWR Typical application Circuitry

PCA9538PWR

An 8-bit General Purpose Input/Output (GPIO) expander with interrupt and reset capabilities for IC-bus and SMBus applications is the PCA9538PWR, which operates at low voltage. It's particularly useful in systems where additional I/O ports are needed without requiring an increase in microcontroller pin count.

Features of PCA9538PWR

1. I/O Expansion: The PCA9538PWR provides 8 additional I/O ports, which can be individually configured as input or output.

2. Interrupt Function: It has an interrupt output, enabling the device to signal the microcontroller when input changes occur.

3. Reset Function: Includes a hardware reset input, allowing the device to be reset without powering down the system.

4. Communication Interface: Equipped with an I²C-bus interface, ensuring easy integration with most microcontrollers or processors.

Application Scenario: Smart Home Lighting System

In a smart home lighting system, the PCA9538PWR can be used to manage multiple light switches and sensors, thereby expanding the I/O capability of the central home automation controller. This application has a comprehensive connection tutorial available here:

Circuit Connection Details

1. Power Supply (VDD - Pin 16, VSS - Pin 8):

- Chip Powering: Power the PCA9538PWR by connecting a reliable power supply to Pin 16 (VDD). Complete the power circuit by grounding VSS (Pin 8).

2. I/O Ports (P0-P7 - Pins 1-7, Pin 9):

- Connecting Switches and Sensors: Wire the light switches and sensors to the I/O ports (P0-P7). The specific configuration will depend on the smart home lighting system's design and the devices being interfaced.

3. I²C Bus Communication (SDA - Pin 15, SCL - Pin 14):

- Home Automation Controller Communication: Connect SDA (Pin 15) and SCL (Pin 14) to the I²C data and clock lines on the home automation controller. This setup facilitates communication between the PCA9538PWR and the controller.

4. Interrupt Configuration (INT - Pin 13):

- Input Change Notification: Connect INT (Pin 13) to an interrupt pin on the home automation controller. This enables the PCA9538PWR to alert the controller when any input state changes.

5. Address Pins (A0-A2 - Pins 10-12):

- I²C Address Customization: Set A0, A1, and A2 (Pins 10-12) to determine the I²C address. This is crucial when multiple devices are connected to the same I²C bus.

6. Hardware Reset (RESET - Pin 11):

- Resetting the Device: Connect RESET (Pin 11) to a reset control line or to a manual switch to allow hardware resetting of the PCA9538PWR if needed.

Design Considerations

When designing a circuit with the PCA9538PWR, consider the following:

1. I/O Pin Capacity: Ensure that the number of I/O pins needed for the switches and sensors does not exceed the 8-bit limit of the PCA9538PWR.

2. I²C Bus Configuration: Properly configure the address of the PCA9538PWR, especially when there are multiple I/O expanders or devices on the same I²C bus.

3. Power Supply Stability: Provide a stable and noise-free power supply to ensure consistent performance of the I/O expander.

4. Interrupt Management: Efficiently handle the interrupt signal to ensure the home automation controller can promptly respond to changes in the input states.

5. Reset Functionality: Ensure the reset functionality is accessible and operates correctly to allow for system troubleshooting or maintenance without requiring a full system power cycle.

By carefully addressing these points and utilizing the functionalities and pin configurations of the PCA9538PWR, one can effectively integrate this I/O expander into sophisticated applications like a smart home lighting system. The PCA9538PWR, with its I/O expansion, interrupt, and reset functionalities, is an excellent choice for enhancing the I/O capabilities of a central home automation controller in complex systems.
