NXP USA Inc. PCA9535PW,112

Part No.:: PCA9535PW,112

Manufacturer:: NXP USA Inc.

Package:: 24-TSSOP (0.173, 4.40mm Width)

Datasheet:: PCA9535PW,112.pdf

Description:: IC I/O EXPANDER I2C 16B 24TSSOP

In Stock:: 3042

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PCA9535PW,112 Specifications

Package/Case:
24-TSSOP (0.173, 4.40mm Width)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
NumberofI/O:
16
Interface:
I²C, SMBus
InterruptOutput:
Yes
Features:
POR
OutputType:
Push-Pull
Current-OutputSource/Sink:
10mA, 25mA
ClockFrequency:
400 kHz
Voltage-Supply:
2.3V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

PCA9535PW,112 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including PCA9535PW,112 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for PCA9535PW,112 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

PCA9535PW,112 information

Views：

PCA9535PW,112 Typical application Circuitry

PCA9535PW,112

The PCA9535PW,112 is a 16-bit I2C-bus and SMBus low-power I/O expander. This chip is designed to provide additional input/output (I/O) capability to a microcontroller or processor, especially in systems with limited GPIO pins. It uses the I2C bus for communication, making it ideal for expanding the I/O capabilities in various applications.

PCA9535PW,112 Application Scenarios:

1. I/O Expansion in Embedded Systems: Commonly used in embedded systems, like in home automation, industrial controls, or IoT devices, where more GPIOs are required for interfacing with additional sensors, LEDs, or other peripherals.

2. Control Functions in Consumer Electronics: Employed in consumer electronics such as smartphones and PCs for managing various control functionalities.

PCA9535PW,112 Key Features and Parameters:

1. 16-Bit I/O Ports: The PCA9535PW,112 provides sixteen additional I/O ports, each configurable as input or output.

2. I2C-Bus Interface: Compatible with the I2C-bus and SMBus, ensuring easy integration into most microcontroller-based systems.

3. Low Power Consumption: Designed for energy efficiency, making it suitable for battery-powered devices.

4. Programmable Polarity Inversion: Includes programmable polarity inversion for the input ports.

5. Wide Voltage Range: Operates within a voltage range of 2.3V to 5.5V, accommodating various logic levels.

Circuit Connection Example: Expanding GPIOs in an IoT Device

Overview: Using PCA9535PW,112 to enhance the number of GPIOs available to a microcontroller in an Internet of Things (IoT) device.

1. Power Supply Connection:

- VDD (pin 24) should be connected to the microcontroller's power supply, typically within the 2.3V to 5.5V range.

2. Ground Connection:

- The system's ground must be connected to GND (pin 12).

3. I2C Bus Integration:

- The microcontroller's I2C data and clock lines should be linked to pins 23 and 22, respectively, for SDA and SCL.

4. Configuring I/O Ports:

- P0.0 to P0.7 (pins 1-7) and P1.0 to P1.7 (pins 13-20) serve as the I/O ports, which can be programmed as inputs or outputs as needed.

5. I2C Address Setting:

- A0, A1, and A2 (pins 21, 20, and 19, respectively) must be set to define the I2C address of the device, by connecting them to either VCC or GND.

Design Considerations:

1. Voltage Level Compatibility: Ensure that VDD is compatible with the logic level voltage of the microcontroller.

2. I2C Address Configuration: Appropriately set A0, A1, and A2 to avoid conflicts on the I2C bus.

3. Pull-Up Resistors on I2C Lines: Incorporate suitable pull-up resistors on SDA and SCL for stable I2C communication.

4. Input/Output Port Configuration: Properly set up P0.0 to P1.7 as inputs or outputs depending on the specific requirements of the IoT device.

5. Power Consumption Management: Be aware of the low power consumption feature, especially in battery-powered applications.

In summary, the PCA9535PW,112 is an effective solution for expanding the GPIO capabilities of microcontroller systems, particularly beneficial in IoT applications and complex electronics. Its 16-bit I/O expansion, compatibility with I2C-bus standards, and energy-efficient design make it a valuable component in various applications where additional GPIOs are essential.
