ON Semiconductor NGTB40N120FL2WG

Part No.:: NGTB40N120FL2WG

Manufacturer:: ON Semiconductor

Package:: TO-247-3

Datasheet:: NGTB40N120FL2WG.pdf

Description:: IGBT TRENCH/FS 1200V 80A TO247

In Stock:: 3539

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NGTB40N120FL2WG Specifications

Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
IGBTType:
Trench Field Stop
Voltage-CollectorEmitterBreakdown(Max):
1200 V
Current-Collector(Ic)(Max):
80 A
Current-CollectorPulsed(Icm):
200 A
Vce(on)(Max)@VgeIc:
2.4V @ 15V, 40A
Power-Max:
535 W
SwitchingEnergy:
3.4mJ (on), 1.1mJ (off)
InputType:
Standard
GateCharge:
313 nC
Td(on/off)@25°C:
116ns/286ns
TestCondition:
600V, 40A, 10Ohm, 15V
ReverseRecoveryTime(trr):
240 ns
OperatingTemperature:
-55°C ~ 175°C (TJ)
MountingType:
Through Hole
