Name: MCP23S17-E/SO
Brand: Microchip Technology
SKU: MCP23S17-E/SO
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology MCP23S17-E/SO

Part No.:: MCP23S17-E/SO

Manufacturer:: Microchip Technology

Package:: 28-SOIC (0.295, 7.50mm Width)

Datasheet:: MCP23S17-E/SO.pdf

Description:: IC I/O EXPANDER SPI 16B 28SOIC

In Stock:: 2771

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MCP23S17-E/SO Specifications

Package/Case:
28-SOIC (0.295, 7.50mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
NumberofI/O:
16
Interface:
SPI
InterruptOutput:
Yes
Features:
POR
OutputType:
Push-Pull
Current-OutputSource/Sink:
25mA
ClockFrequency:
10 MHz
Voltage-Supply:
1.8V ~ 5.5V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
