Name: MAX4426MJA/883B
Brand: Analog Devices Inc./Maxim Integrated
SKU: MAX4426MJA/883B
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc./Maxim Integrated MAX4426MJA/883B

Part No.:: MAX4426MJA/883B

Manufacturer:: Analog Devices Inc./Maxim Integrated

Package:: 8-CDIP (0.300, 7.62mm)

Datasheet:: MAX4426MJA/883B.pdf

Description:: IC GATE DRVR LOW-SIDE 8CERDIP

In Stock:: 2789

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MAX4426MJA/883B Specifications

Packaging:
Tube
Series:
Military, MIL-STD-883
ProductStatus:
Active
DrivenConfiguration:
Low-Side
ChannelType:
Independent
NumberofDrivers:
2
GateType:
N-Channel, P-Channel MOSFET
Voltage-Supply:
4.5V ~ 18V
LogicVoltage-VILVIH:
0.8V, 2.4V
Current-PeakOutput(SourceSink):
1.5A, 1.5A
InputType:
Inverting
HighSideVoltage-Max(Bootstrap):
-
Rise/FallTime(Typ):
20ns, 20ns
OperatingTemperature:
-55°C ~ 125°C (TA)
MountingType:
Through Hole
