Name: LM5101ASDX-1/NOPB
Brand: Texas Instruments
SKU: LM5101ASDX-1/NOPB
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments LM5101ASDX-1/NOPB

Part No.:: LM5101ASDX-1/NOPB

Manufacturer:: Texas Instruments

Package:: 8-WDFN Exposed Pad

Datasheet:: LM5101ASDX-1/NOPB.pdf

Description:: IC GATE DRVR HALF-BRIDGE 8WSON

In Stock:: 3254

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LM5101ASDX-1/NOPB Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
DrivenConfiguration:
Half-Bridge
ChannelType:
Independent
NumberofDrivers:
2
GateType:
N-Channel MOSFET
Voltage-Supply:
9V ~ 14V
LogicVoltage-VILVIH:
2.3V, -
Current-PeakOutput(SourceSink):
3A, 3A
InputType:
Non-Inverting
HighSideVoltage-Max(Bootstrap):
118 V
Rise/FallTime(Typ):
430ns, 260ns
OperatingTemperature:
-40°C ~ 125°C (TJ)
MountingType:
Surface Mount
