Name: ISL83202IBZ
Brand: Renesas Electronics America Inc
SKU: ISL83202IBZ
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Renesas Electronics America Inc ISL83202IBZ

Part No.:: ISL83202IBZ

Manufacturer:: Renesas Electronics America Inc

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: ISL83202IBZ.pdf

Description:: IC GATE DRVR HALF-BRIDGE 16SOIC

In Stock:: 3406

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ISL83202IBZ Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Active
DrivenConfiguration:
Half-Bridge
ChannelType:
Independent
NumberofDrivers:
4
GateType:
N-Channel MOSFET
Voltage-Supply:
8.5V ~ 15V
LogicVoltage-VILVIH:
1V, 2.5V
Current-PeakOutput(SourceSink):
1A, 1A
InputType:
Inverting, Non-Inverting
HighSideVoltage-Max(Bootstrap):
70 V
Rise/FallTime(Typ):
9ns, 9ns
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
