Infineon Technologies IR2153STR

Part No.:: IR2153STR

Manufacturer:: Infineon Technologies

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: IR2153STR.pdf

Description:: IC GATE DRVR HALF-BRIDGE 8SOIC

In Stock:: 2009

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

IR2153STR Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
DrivenConfiguration:
Half-Bridge
ChannelType:
Synchronous
NumberofDrivers:
2
GateType:
N-Channel MOSFET
Voltage-Supply:
10V ~ 15.6V
LogicVoltage-VILVIH:
-
Current-PeakOutput(SourceSink):
-
InputType:
RC Input Circuit
HighSideVoltage-Max(Bootstrap):
600 V
Rise/FallTime(Typ):
80ns, 45ns
OperatingTemperature:
-40°C ~ 125°C (TJ)
MountingType:
Surface Mount

IR2153STR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including IR2153STR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for IR2153STR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

IR2153STR information

Views：

IR2153STR Typical application Circuitry

IR2153STR

The IR2153STR is an eminent self-oscillating half-bridge driver from International Rectifier, specifically tailored to steer power MOSFETs and IGBTs. Recognized for its compactness and efficiency, the IR2153STR's features encapsulate the essence of simplified, cost-effective designs, especially in applications like switch mode power supplies and resonant mode converters. This write-up strives to offer an in-depth roadmap to seamlessly interface the IR2153STR within a circuit, ensuring accurate pin-level delineation.

1. VCC: As the primary supply terminal, it requires an attachment to a voltage source within the range outlined in the datasheet, commonly around 10-20V.

2. RT/CT: This is an intriguing dual-purpose pin. Attach a resistor (RT) from this pin to VCC to set the internal oscillator's frequency. Subsequently, connect a capacitor (CT) from this pin to ground, fine-tuning the oscillator's operational duty cycle.

3. LO (Low Side Gate Output): This terminal manages the gate drive for the low-side MOSFET or IGBT. Establish a direct linkage between this pin and the gate of the low-side semiconductor.

4. HO (High Side Gate Output): Connect this terminal straight to the high-side component's gate, as it is intended to control the gate of the high-side MOSFET or IGBT.

5. VS: Ordinarily, this pin finds its connection at the source of the high-side MOSFET or IGBT. In addition, it serves as the bootstrap capacitor's reference point.

6. VB: Serving as a floating terminal to cater to the high-side gate drive supply, a bootstrap capacitor typically connects between VB and VS to ensure adequate drive voltage for the high-side switch.

7. COM: Representing the common ground for the logic circuits, make sure to unify this terminal with the system ground.

8. Vref/SD (Reference Voltage/Shutdown): This multi-functional pin outputs a reference voltage, usually around 10V. An externally applied voltage below a specific threshold will shut down the IR2153STR.

9. Enhancing Performance & Safety:

- Bootstrap Mechanics: Enlist an external capacitor and diode to develop a bootstrap supply for the high-side driver. The diode's anode should connect to VCC, its cathode to VB, and the capacitor should span between VB and VS.

- Decoupling Stratagem: To suppress potential noise and stabilize the IC, consider integrating a ceramic capacitor proximate to the IR2153STR, bridging VCC and COM.

10. Insightful Recommendations: Keeping an eye on potential cross-conduction is vital, ensuring that the half-bridge doesn't face "shoot-through" conditions. Regularly verify that VCC lies comfortably within the bounds specified in the IR2153STR's documentation.
