Infineon Technologies AUIRB24427STR

Part No.:: AUIRB24427STR

Manufacturer:: Infineon Technologies

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AUIRB24427STR.pdf

Description:: IC GATE DRVR LOW-SIDE 8SOIC

In Stock:: 2824

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AUIRB24427STR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Obsolete
DrivenConfiguration:
Low-Side
ChannelType:
Independent
NumberofDrivers:
2
GateType:
N-Channel MOSFET
Voltage-Supply:
5V ~ 20V
LogicVoltage-VILVIH:
0.8V, 2.5V
Current-PeakOutput(SourceSink):
6A, 6A
InputType:
Non-Inverting
HighSideVoltage-Max(Bootstrap):
-
Rise/FallTime(Typ):
33ns, 33ns (Max)
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
