Analog Devices Inc. AD5290YRMZ10

Part No.:: AD5290YRMZ10

Manufacturer:: Analog Devices Inc.

Package:: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)

Datasheet:: AD5290YRMZ10.pdf

Description:: IC DGTL POT 10KOHM 256TAP 10MSOP

In Stock:: 2495

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5290YRMZ10 Specifications

Package/Case:
10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
Taper:
Linear
Configuration:
Potentiometer
NumberofCircuits:
1
NumberofTaps:
256
Resistance(Ohms):
10k
Interface:
SPI
MemoryType:
Volatile
Voltage-Supply:
4.5V ~ 33V, ±4.5V ~ 16.5V
Features:
Cascade Pin
Tolerance:
±30%
TemperatureCoefficient(Typ):
35ppm/°C
MountingType:
Surface Mount
OperatingTemperature:
-40°C ~ 125°C
