A typical application for the AD5282BRUZ200 is in an adjustable power supply, where it is used to fine-tune the output voltage by adjusting the feedback resistance.
Circuit Design Example:
1. Power Connections: Connect the VDD pin (Pin 16) to a +5V power supply and the VSS pin (Pin 8) to the system ground.
2. Digital Interface: Interface the AD5282BRUZ200 with a microcontroller using the SDA (Pin 14), SCL (Pin 15), and A0 (Pin 1) pins for I2C communication. These connections allow the microcontroller to set the resistance values of the digital potentiometer.
3. Potentiometer Connections: Connect the Wiper (W) pin (Pins 6 and 12) of each potentiometer channel to the feedback network of the power supply. Connect the High (H) and Low (L) pins (Pins 5 and 7 for channel A, Pins 11 and 13 for channel B) to the appropriate points in the circuit to create a variable resistor.
4. Reset: Connect the RESET pin (Pin 9) to the microcontroller to allow resetting the digital potentiometer to its default state if needed.
Design Considerations:
- I2C Addressing: Ensure that the address pins (A0, A1, A2) are correctly set to avoid conflicts with other I2C devices on the bus.
- Power Supply Stability: Use a stable power supply for VDD and VSS to ensure consistent operation of the digital potentiometer.
- Signal Integrity: Keep the digital communication lines (SDA, SCL) free from noise to ensure reliable communication between the microcontroller and the AD5282BRUZ200.
- Thermal Considerations: To avoid overheating, be mindful of the digital potentiometer's power dissipation and make sure it stays within the designated ranges.
By following these design considerations, the AD5282BRUZ200 can be effectively used in an adjustable power supply to provide precise control over the output voltage.
