Analog Devices Inc. AD5263BRUZ200

Part No.:: AD5263BRUZ200

Manufacturer:: Analog Devices Inc.

Package:: 24-TSSOP (0.173, 4.40mm Width)

Datasheet:

Description:: IC DGT POT 200KOHM 256TP 24TSSOP

In Stock:: 2207

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5263BRUZ200 Specifications

Package/Case:
24-TSSOP (0.173, 4.40mm Width)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
Taper:
Linear
Configuration:
Potentiometer
NumberofCircuits:
4
NumberofTaps:
256
Resistance(Ohms):
200k
Interface:
I²C, SPI
MemoryType:
Volatile
Voltage-Supply:
4.5V ~ 16.5V, ±4.5V ~ 7.5V
Features:
Cascade Pin, Selectable Address
Tolerance:
±30%
TemperatureCoefficient(Typ):
30ppm/°C
MountingType:
Surface Mount
OperatingTemperature:
-40°C ~ 125°C

AD5263BRUZ200 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD5263BRUZ200 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD5263BRUZ200 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD5263BRUZ200 information

Views：

AD5263BRUZ200 Typical application Circuitry

AD5263BRUZ200

The AD5263BRUZ200 is a digital potentiometer with four independent 200 kΩ channels, designed for applications that require precise adjustment of resistance values. It's widely used in audio volume control, signal conditioning, and calibration systems. The device operates with an SPI interface, allowing for easy integration with microcontrollers and digital systems.

Key Specifications:

- Quad-channel: Offers four independent channels for multiple adjustments.

- 200 kΩ resistance range: Ideal for applications requiring high resistance values.

- SPI interface: Simplifies communication with microcontrollers.

Application Scenario: Temperature Control System

Circuit Design:

1. Power Supply: Connect VDD (pin 24) to a 5V source and GND (pin 13) to the system ground.

2. SPI Configuration: Link SCLK (pin 23) to the AD5263BRUZ200 SPI clock of the microcontroller, SDI (pin 22) to SPI MOSI, and SDO (pin 21) to SPI MISO. Attach CS (pin 20) to a microcontroller digital output for chip selection.

3. Temperature Sensor Integration: Connect a temperature sensor's output to the Wiper (W1, pin 1) of the first potentiometer channel. Join Terminal A (A1, pin 2) to the sensor's power supply and Terminal B (B1, pin 3) to the sensor's ground. By adjusting the wiper position, you can calibrate the sensor's output.

4. Digital Calibration: Utilize SPI commands to alter the resistance between the Wiper (W) and Terminal A (A) for sensor output calibration.

Design Considerations:

- Power Decoupling: Place a 0.1 µF bypass capacitor near the VDD and GND pins to reduce noise.

- SPI Timing: Ensure that the SPI communication with the AD5263BRUZ200 adheres to the specified timing requirements for reliable operation.

- Temperature Sensor Compatibility: Choose a temperature sensor compatible with the resistance range and resolution of the AD5263BRUZ200 for effective calibration.

By following these guidelines, you can effectively utilize the AD5263BRUZ200 in a temperature control system, showcasing its capability to provide precise resistance adjustments for sensor calibration.
