Texas Instruments UA741CPS

Part No.:: UA741CPS

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: UA741CPS.pdf

Description:: IC OPAMP GP 1 CIRCUIT 8SO

In Stock:: 2300

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

UA741CPS Specifications

Package/Case:
8-SOIC (0.209, 5.30mm Width)
Packaging:
Bulk
Series:
-
ProductStatus:
Active
AmplifierType:
General Purpose
NumberofCircuits:
1
OutputType:
-
SlewRate:
0.5V/µs
GainBandwidthProduct:
-
-3dbBandwidth:
-
Current-InputBias:
80 nA
Voltage-InputOffset:
1 mV
Current-Supply:
1.7mA
Current-Output/Channel:
25 mA
Voltage-SupplySpan(Min):
10 V
Voltage-SupplySpan(Max):
30 V
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount

UA741CPS this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including UA741CPS price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for UA741CPS to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

UA741CPS information

Views：

UA741CPS Typical application Circuitry

UA741CPS

Operational amplifiers, or op-amps, like the UA741CPS are well-known for their versatility in electrical circuit applications. This particular chip is a general-purpose op-amp, valued for its versatility, reliability, and straightforward implementation in various applications.

Functionality of UA741CPS

The UA741CPS primarily functions as an op-amp, designed to amplify analog voltage signals. It is configurable in multiple circuit arrangements, including inverting, non-inverting, differential, voltage follower, and integrator setups.

Application Scenarios

- Audio Amplification: Commonly used in audio systems for signal amplification.

- Sensor Signal Processing: Integral in conditioning and amplifying signals from sensors in measurement devices.

- Active Filtering: Employed in creating various types of analog filters (low-pass, high-pass, band-pass).

- Analog Computations: Utilized for performing mathematical operations such as addition, subtraction, and integration in analog signal processing.

Parameter Features

- Input Offset Voltage: Generally in the range of a few millivolts, important for precision applications.

- Supply Voltage Range: Usually functions within the range of ±5V to ±18V.

- Input Bias Current: Usually in the nanoampere range.

- Gain Bandwidth Product: Approximately 1 MHz, suitable for applications within this frequency range.

Application Example: Non-Inverting Amplifier

1.Input Signal

- Pin 3 (Non-Inverting Input): Connects to the input signal.

- Consideration: The input signal voltage should be within the operational range of the UA741CPS.

2.Output Connection

- Pin 6 (Output): This pin provides the amplified signal.

- Consideration: It's essential to ensure that the output does not exceed the power supply limits to avoid distortion.

3.Grounding in Single Supply Operations

- Pin 4 (Negative Supply): In single-supply operations, this pin is often connected to the ground.

- Consideration: Proper grounding is crucial to minimize noise and ensure stable operation.

4.Bypass Capacitors

- Close to Pins 4 (Negative Supply) and 7 (Positive Supply).

- Consideration: Using bypass capacitors close to the power supply pins is recommended to stabilize the supply and reduce noise.

Design Considerations

Incorporating the UA741CPS into a circuit design involves several important considerations:

1. Power Supply Limitations: The power supply should be within the operational range of the op-amp to avoid damage or instability.

2. Input and Output Voltage Range: The input and output voltages should be maintained within the acceptable range of the op-amp to prevent clipping and ensure accurate amplification.

3. Gain Configuration: The amplifier's gain is set by the resistor network connected to the feedback loop. These resistors should be chosen based on the desired level of amplification.

4. Load Capability: The UA741CPS can only drive certain loads effectively. Ensure the load is within the driving capacity of the op-amp.

5. Thermal Management: Be aware of the heat generated by the op-amp, especially in high-frequency or high-voltage applications, and provide adequate cooling if necessary.

6. Frequency Response and Stability: Consider the gain-bandwidth product and phase margin of the UA741CPS to ensure stability and appropriate frequency response for the intended application.

7. Noise Reduction: Noise can be a significant issue in analog circuits. Implementing strategies such as careful layout, shielding, and the use of bypass capacitors can help minimize noise.

Conclusion

The UA741CPS is a fundamental component in analog electronics, offering flexibility and reliability in a wide range of applications. Its widespread use is attributed to its straightforward implementation and effectiveness in various circuit configurations. Successful circuit deployment with the UA741CPS requires a thorough understanding of its specifications and characteristics, as well as careful consideration of external factors like power supply, load conditions, and environmental influences. By addressing these considerations, the UA741CPS can be effectively utilized for diverse electronic applications, from simple signal amplification to complex analog computations.
