INA210AIDCKT this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including INA210AIDCKT price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for INA210AIDCKT to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
There is no doubt that you may place an order without registering to icwhale.com.
We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.
For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.
It is recommended to acquire for quotations to get the latest prices and inventories about the parts.
Our sales will reply to your request by email within 24 hours.
1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.
Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.
Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.
Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.
Views:
Broad Application Spectrum: The INA210AIDCKT is widely employed in systems such as battery management, energy-efficient power supplies, overcurrent protection circuits, and precise current sensing in embedded systems. Its ability to provide real-time, accurate current measurements makes it a key player in optimizing power management strategies.
Core Attributes: The INA210AIDCKT is distinguished by:
- An input common-mode voltage range from -0.3V to +26V, accommodating a wide range of application scenarios.
- Exceptional accuracy, highlighted by a maximum offset voltage of ±100µV and a gain error limited to ±0.5%.
- A notably low quiescent current of 60µA, enhancing its suitability for battery-powered devices.
- A fixed gain of 200V/V, enabling the amplification of small voltage drops across shunt resistors for straightforward measurement.
Illustrative Circuit Design-Overcurrent Protection System:
1. Power Supply Integration: Connect the V+ pin of the INA210AIDCKT to a stable 3.3V supply, ensuring the amplifier operates within its optimal voltage range.
2. Shunt Resistor Placement: Install a precision shunt resistor (R_SHUNT) in the path of the current to be monitored. Interface the INA210AIDCKT's IN+ pin directly with the source side of the resistor and the IN- pin with the load side.
3. Output Signaling: Tie the OUT pin to a comparator or microcontroller input configured to detect overcurrent conditions based on the voltage level corresponding to a predefined current threshold.
4. Signal Filtering: Implement a low-pass filter by attaching a capacitor between the OUT pin and ground to attenuate high-frequency noise and stabilize the signal.
Strategic Design Considerations:
- Shunt Resistor Accuracy: Choose a resistor with minimal temperature dependency and strict tolerance levels to ensure precise current measurement.
- Stable Power Supply: Utilize decoupling capacitors near the V+ pin to counteract potential power supply fluctuations.
- Comparator Threshold Calibration: Adjust the comparator's threshold to match the voltage level at the OUT pin that corresponds to the maximum allowable current.
- Thermal Management: Evaluate the thermal effects on the shunt resistor and INA210AIDCKT, as excessive heat can distort measurements. Effective thermal management practices are crucial.
By following these detailed component selection and circuit design guidelines, the INA210AIDCKT can be seamlessly integrated into an overcurrent protection system, providing precise monitoring of current and enhancing the system's safety and reliability.
