Texas Instruments UA741CP

Part No.:: UA741CP

Manufacturer:: Texas Instruments

Package:: 8-DIP (0.300, 7.62mm)

Datasheet:: UA741CP.pdf

Description:: IC OPAMP GP 1 CIRCUIT 8DIP

In Stock:: 32048

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

UA741CP Specifications

Package/Case:
8-DIP (0.300, 7.62mm)
Packaging:
Tube
Series:
-
ProductStatus:
Active
AmplifierType:
General Purpose
NumberofCircuits:
1
OutputType:
-
SlewRate:
0.5V/µs
GainBandwidthProduct:
1 MHz
-3dbBandwidth:
-
Current-InputBias:
80 nA
Voltage-InputOffset:
1 mV
Current-Supply:
1.7mA
Current-Output/Channel:
25 mA
Voltage-SupplySpan(Min):
7 V
Voltage-SupplySpan(Max):
36 V
OperatingTemperature:
0°C ~ 70°C
MountingType:
Through Hole

UA741CP this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including UA741CP price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for UA741CP to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

UA741CP information

Views：

UA741CP Typical application Circuitry

UA741CP

The UA741CP is a widely used operational amplifier (op-amp) chip, known for its versatility and ease of use in various electronic circuits. It's a fundamental component in analog signal processing and is used in a myriad of applications due to its simplicity and effectiveness.

Functionality of UA741CP

The UA741CP functions as an operational amplifier, which is used to amplify voltage signals. Its primary features include a high gain, wide range of operating voltages, and a single-ended input.

Application Scenarios

- Audio Amplifiers: Commonly used to amplify audio signals in small speakers or headphones.

- Analog Filters: Essential for building band-pass, high-pass, and low-pass filters, among other filter types.

- Signal Conditioning: Used to condition and amplify signals in instrumentation and measurement devices.

- Voltage Comparators: Can be configured to compare input voltages and output a corresponding signal.

Parameter Features

- Input Offset Voltage: Typically around 1 mV.

- Supply Voltage Range: Usually between ±5V to ±15V.

- Input Bias Current: Generally in the range of 80 nA.

- Gain Bandwidth Product: Approximately 1 MHz.

Application Example: Non-Inverting Amplifier Circuit

1.Power Supply

- Pins 7 (V+) and 4 (V-): The positive and negative power supplies are linked to these pins, respectively.

- Take into account: For best results, the supply voltage should be within the given range.

- Pin 3 (Non-Inverting Input): This pin receives the input signal applied to it.

- Consideration: Ensure that the input signal voltage is within the operating range of the UA741CP.

2.Feedback and Gain Control

- Pin 2 (Inverting Input) and Pin 6 (Output): A resistor network between these pins sets the gain of the amplifier.

- Consideration: The values of the resistors determine the amplification factor, so they must be chosen based on the desired gain.

3.Output

- Pin 6 (Output): This pin provides the amplified signal.

- Consideration: The output should be monitored to ensure it does not exceed the supply voltage limits.

4.Bypass Capacitors

- Near Pin 7 (V+) and Pin 4 (V-)

- Consideration: Placing bypass capacitors close to the power supply pins helps in stabilizing the voltage supply and reducing noise.

5.Grounding

- Pin 4 (V-): In a single-supply operation, this pin is often connected to the ground.

- Consideration: Proper grounding is essential to prevent noise and ensure stable operation.

Design Considerations

A number of important considerations need to be made when developing circuits with the UA741CP:

1. Power Supply Range: The power supply voltage should be within the specified limits to prevent damage to the op-amp.

2. Input Signal Range: The input signal voltage should not exceed the voltage range that the op-amp can handle.

3. Gain Setting: The gain of the amplifier is determined by the resistor network connected between the inverting input and the output. This needs to be calculated and set according to the desired amplification.

4. Output Load: The output of the UA741CP can drive only limited loads. Ensure the load connected to the output is within the op-amp's capability.

5. Temperature Effects: The performance of the UA741CP can vary with temperature. Thus, if used in a temperature-sensitive environment, this needs to be considered.

6. Frequency Response: The gain bandwidth product of the op-amp limits its use in high-frequency applications. The circuit design should account for this limitation.

Conclusion

The UA741CP is a fundamental component in analog electronics, offering a simple yet effective solution for a wide range of applications including signal amplification and conditioning. Many circuit designers choose it because of its accessibility and ease of usage. But for implementation to be successful, a number of things need to be carefully taken into account, including the operational environment, input and output limits, power supply, and gain setting. By paying attention to these aspects, one can harness the full potential of the UA741CP in various electronic applications.
