Texas Instruments TPS3808G33QDBVRQ1

Part No.:: TPS3808G33QDBVRQ1

Manufacturer:: Texas Instruments

Package:: SOT-23-6

Datasheet:: TPS3808G33QDBVRQ1.pdf

Description:: IC SUPERVISOR 1 CHANNEL SOT23-6

In Stock:: 2452

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TPS3808G33QDBVRQ1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
Automotive, AEC-Q100
ProductStatus:
Active
Type:
Simple Reset/Power-On Reset
NumberofVoltagesMonitored:
1
Voltage-Threshold:
3.07V
Output:
Open Drain or Open Collector
Reset:
Active Low
ResetTimeout:
Adjustable/Selectable
OperatingTemperature:
-40°C ~ 125°C (TJ)
MountingType:
Surface Mount
