Texas Instruments TPS3808G01DBVR

Part No.:: TPS3808G01DBVR

Manufacturer:: Texas Instruments

Package:: SOT-23-6

Datasheet:: TPS3808G01DBVR.pdf

Description:: IC SUPERVISOR 1 CHANNEL SOT23-6

In Stock:: 2402

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TPS3808G01DBVR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
Type:
Simple Reset/Power-On Reset
NumberofVoltagesMonitored:
1
Voltage-Threshold:
Adjustable/Selectable
Output:
Open Drain or Open Collector
Reset:
Active Low
ResetTimeout:
Adjustable/Selectable
OperatingTemperature:
-40°C ~ 125°C (TJ)
MountingType:
Surface Mount

TPS3808G01DBVR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including TPS3808G01DBVR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for TPS3808G01DBVR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

TPS3808G01DBVR information

Views：

TPS3808G01DBVR Typical application Circuitry

TPS3808G01DBVR

TPS3808G01DBVR is a precision voltage supervisor chip designed by Texas Instruments. It's primarily used for monitoring the voltage levels in digital systems and initiating a reset sequence if these levels fall outside of predefined thresholds. This chip is essential in maintaining system reliability and stability.

Application Scenarios: TPS3808G01DBVR is frequently implemented in environments like microprocessor systems, embedded systems, portable devices, and industrial controls, where maintaining accurate voltage levels is critical for proper functioning.

Parameter Features:

- Specific Voltage Supervision: Optimized for supervising 1.0V power supplies.

- Programmable Reset Delay: Enables programming of the delay time for the reset signal.

- Low Power Consumption: Its energy efficiency is ideal for battery-powered devices.

- Compact Form Factor: Comes in a small SOT-23 package, fitting for space-constrained applications.

- Wide Operating Temperature Range: Can operate effectively across various environmental conditions.

Circuit Connection in an Embedded System:

1. Power Supply Connection: Attach the VDD pin of TPS3808G01DBVR to the 1.0V power line of the embedded system.

2. Effective Grounding: The GND pin of TPS3808G01DBVR must be connected to the system's ground for stability and noise reduction.

3. Reset Signal Configuration: Link the RESET pin of TPS3808G01DBVR to the reset input of the embedded system's processor, enabling it to trigger a reset when the voltage falls below the threshold.

4. Delay Time Customization: An external capacitor should be connected to the CT pin to set the desired reset delay time, allowing for flexibility in system response.

5. Input Voltage Stabilization: Install a decoupling capacitor near the VDD pin to ensure the input voltage is stable and free from noise.

6. Monitoring Voltage Threshold Setup: Adjust the monitoring threshold of TPS3808G01DBVR to match the critical voltage level necessary for the embedded system.

7. Optimized PCB Layout: Design the PCB to minimize the path length between TPS3808G01DBVR and the processor, reducing signal degradation and interference.

8. Environmental Adaptability: Ensure that TPS3808G01DBVR is placed in a position on the PCB that can handle environmental stresses, such as temperature variations typical in embedded system applications.

Design Considerations:

1. Voltage Level Suitability: Confirm the compatibility of TPS3808G01DBVR's operating voltage range with the embedded system's power supply.

2. Reset Timing Accuracy: Carefully design the delay timing to make sure the system reset occurs at the appropriate time.

3. Energy Efficiency: Optimize the circuit for low power consumption, especially important in portable or energy-sensitive systems.

4. System Protection Strategies: Include protective elements to shield TPS3808G01DBVR and the overall system from electrical disturbances like overvoltage or transient spikes.

Following these comprehensive design guidelines and specific circuit connection instructions for TPS3808G01DBVR, designers can effectively incorporate this chip into embedded systems. This integration ensures accurate voltage monitoring, timely system resets, and enhances the overall reliability and stability of the system in various operational contexts.
