Texas Instruments TLV320AIC23BPWRG4

Part No.:: TLV320AIC23BPWRG4

Manufacturer:: Texas Instruments

Package:: 28-TSSOP (0.173, 4.40mm Width)

Datasheet:: TLV320AIC23BPWRG4.pdf

Description:: IC STEREO AUDIO CODEC 28-TSSOP

In Stock:: 2327

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLV320AIC23BPWRG4 Specifications

Package/Case:
28-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Discontinued at Mosen
Type:
Stereo Audio
DataInterface:
I²C, Serial
Resolution(Bits):
16 b, 20 b, 24 b, 32 b
NumberofADCs/DACs:
2 / 2
SigmaDelta:
Yes
S/NRatioADCs/DACs(db)Typ:
90 / 100
DynamicRangeADCs/DACs(db)Typ:
90 / 90
Voltage-SupplyAnalog:
2.7V ~ 3.6V
Voltage-SupplyDigital:
1.42V ~ 3.6V
OperatingTemperature:
-10°C ~ 70°C
MountingType:
Surface Mount
