ADV212BBCZ-150 Typical application Circuitry

ADV212BBCZ-150

The ADV212BBCZ-150 is a sought-after JPEG2000 codec produced by Analog Devices. It provides video compression and decompression capabilities with both lossy and lossless options. For incorporating this device into your circuit, follow the guide outlined below:

1. Power Connections: Supply power by attaching the VDD pins (Pins 16, 17, 29, 36, 37, 38, 40, 41, 57, 58, 72, 73, 74, 76, 77, 93, 94, 108, 109, 110, 112, 113, 129, 130, 144) to a 1.8V power source and the RADIO pins (Pins 13, 14, 15, 45, 46, 81, 82, 117, 118, 119) to a 3.3V power source. Link all GND pins (Pins 1, 18, 39, 42, 43, 59, 75, 78, 95, 111, 114, 131, 140, 141, 142) to your power supply's ground.

2. Clock Input: CLI (Pin 80) is where you should input your external 27 MHz clock signal.

3. Reset Configuration: The RESET pin (Pin 79) is active low. Typically, this pin is held high by a pull-up resistor linked to the 3.3V supply. To execute a reset of the ADV212BBCZ-150, take this pin low.

4. Data Bus Link: The data bus of the ADV212BBCZ-150 is bidirectional and 16-bit (DB[15:0], Pins 48-63). Connect this bus to the corresponding data bus on your processor or microcontroller.

5. Control Signal Integration: The control signals from your processor or microcontroller, such as Chip Select (CS, Pin 66), Read (RD, Pin 68), and Write (WR, Pin 70) should be connected to the respective control signal pins on the ADV212BBCZ-150. Address lines A0 and A1 (Pins 64, 65) are used for register selection and should be connected accordingly.

6. Interrupt Setup: IRQ (Pin 67) is an active low output pin used to trigger an interrupt in the microcontroller or processor. It should be connected to an appropriate interrupt input on your controller.

The actual deployment of the ADV212BBCZ-150 in a circuit often requires additional circuitry to meet the particular requirements of a project. Therefore, when assembling your circuit, ensure all components are connected as per their specifications and the specific requirements of your application.

ADV212BBCZ-150 information

ADV212BBCZ-150 Specifications

Package/Case:
144-BGA, CSPBGA
Packaging:
Tray
Series:
Wavescale®
ProductStatus:
Active
Type:
Video, JPEG2000
DataInterface:
-
Resolution(Bits):
16 b
NumberofADCs/DACs:
-
SigmaDelta:
No
S/NRatioADCs/DACs(db)Typ:
-
DynamicRangeADCs/DACs(db)Typ:
-
Voltage-SupplyAnalog:
1.5V, 3.3V
Voltage-SupplyDigital:
1.5V, 3.3V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
