Texas Instruments TLV320AIC23BIPWRQ1

Part No.:: TLV320AIC23BIPWRQ1

Manufacturer:: Texas Instruments

Package:: 28-TSSOP (0.173, 4.40mm Width)

Datasheet:: TLV320AIC23BIPWRQ1.pdf

Description:: IC STEREO AUDIO CODEC 28-TSSOP

In Stock:: 58012

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLV320AIC23BIPWRQ1 Specifications

Package/Case:
28-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
Automotive, AEC-Q100
ProductStatus:
Active
Type:
Stereo Audio
DataInterface:
I²C
Resolution(Bits):
16 b, 20 b, 24 b, 32 b
NumberofADCs/DACs:
2 / 2
SigmaDelta:
Yes
S/NRatioADCs/DACs(db)Typ:
90 / 100
DynamicRangeADCs/DACs(db)Typ:
90 / 90
Voltage-SupplyAnalog:
2.7V ~ 3.6V
Voltage-SupplyDigital:
1.42V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
