Toshiba Semiconductor and Storage TLP5701(TP4,E

Part No.:: TLP5701(TP4,E

Manufacturer:: Toshiba Semiconductor and Storage

Package:: 6-SOIC (0.295, 7.50mm Width)

Datasheet:: TLP5701(TP4,E.pdf

Description:: PHOTOCOUPLER

In Stock:: 2986

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLP5701(TP4,E Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
Technology:
Optical Coupling
NumberofChannels:
1
Voltage-Isolation:
5000Vrms
CommonModeTransientImmunity(Min):
20kV/µs
PropagationDelaytpLH/tpHL(Max):
500ns, 500ns
PulseWidthDistortion(Max):
350ns
Rise/FallTime(Typ):
50ns, 50ns
Current-OutputHighLow:
400mA, 400mA
Current-PeakOutput:
600mA
Voltage-Forward(Vf)(Typ):
1.57V
Current-DCForward(If)(Max):
25 mA
Voltage-OutputSupply:
10V ~ 30V
OperatingTemperature:
-40°C ~ 110°C
MountingType:
Surface Mount
