Texas Instruments TLC3578IPWR

Part No.:: TLC3578IPWR

Manufacturer:: Texas Instruments

Package:: 24-TSSOP (0.173, 4.40mm Width)

Datasheet:: TLC3578IPWR.pdf

Description:: IC ADC 14BIT SAR 24TSSOP

In Stock:: 2015

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLC3578IPWR Specifications

Packaging:
Tape & Reel (TR)
Series:
-
Product Status:
Active
Number of Bits:
14
Sampling Rate(PerSecond):
200k
Number of Inputs:
4, 8
Input Type:
Pseudo-Differential, Single Ended
Data Interface:
SPI
Configuration:
MUX-S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
SAR
Reference Type:
External
Voltage-Supply Analog:
5V
Voltage-Supply Digital:
2.7V ~ 5.5V
Features:
-
Operating Temperature:
-40°C ~ 85°C
